DMP RoBoard Starter Kit with RB-100
Details
DMP RoBoard Starter Kit with RB-100. Vortex86DX, a 32bit x86 CPU 1000MHz, 256MB DRAM. Windows, Linux, DOS compatible, 96 x 56 mm, Anti-Power Protection, High-speed serial ports supported. (Integrated FTDI-FT2232HL), rich I/O interfaces to the servo, DC motors, sensors, gyroscope, accelerometers and other devices. Also, it has build-in the PWM up to 32 Ch, GPIO,RS-232 serial, TTL serial, RS-485,USB V2.0 x 3, A/D convert, SPI/I2C bus, Audio out & Mic in, 10/100M LAN and Mini PCI socket. Kit includes: RB-100 Main Board(Hardware only), RB-100-Cable (COM ports, LAN, Audio and A/D cable), MiniPCI-VGA (Mini PCI VGA for development), and Mini-PCI-WLAN-Card (Mini PCI Wireless Card). PN: RB-100
