Connect Tech's GraphiteVPX/CPU-TX2/TX2i/TX1
>View GraphiteVPX/CPU-TX2/TX2i/TX1 from WDL Systems
Connect Tech’s GraphiteVPX/CPU-TX2/TX2i/TX1 is a VITA 65 compliant 3U VPX single board computer that brings the NVIDIA® Jetson™ TX2, TX2i and TX1 embedded computing platforms to the VPX form factor. This complete host solution delivers over a TeraFLOP of performance, with multiple USB 3.0 ports, multiple GbE channels, and 6 x CSI camera interfaces to round out this 3U VPX solution. The onboard PCIe Gen 3.0 switch allows for two x4 interfaces providing two additional downstream ports on the backplane. The GraphiteVPX/CPU-TX2/TX2i/TX1 has a Quad-Core 64bit ARM Cortex-A57 processor.
Key Features:
- 1 TFLOP, 256 CUDA cores with NVIDIA® Pascal™ or Maxwell™ GPU Architecture
- Conduction cooled
- The onboard PCIe Gen 3.0 switch supports two x4 port dataplane connections
- Extended Temperature Range -40°C to +85°C (TX2i)
- Can be used with RTG004 Graphite VPX CPU TX2/TX1 RTM to aid in development
